Introduction

Besides the fact that the Earth is the cradle of life, it is also a huge magnetic body. The planet is covered with a blanket of a pervasive geomagnetic field that guides the compasses, which are full of iron, and at the same time provides protection against harmful cosmic radiations and the solar wind particles. This natural self-generated shield- what is commonly referred to as Earth magnetism or geomagnetic field- is a fascinating natural process that has been prevalently researched under the field of geophysics as well as space science.

The terrestrial field is of the order of 10⁻⁵ Tesla, which is rather small in comparison with the magnetic fields generated in the laboratory. However, at the planetary scale, such strength is enough to affect the operation of navigation systems, atmospheric processes, and space weather. The spatial variation of the field according to both satellite and ground-based observatories can be measured quantitatively, which shows that the field is more complex and its structure changes over time.

The formation, nature, and effects of the magnetic field on the Earth require a dual emphasis on the geodynamo processes that are taking place in both the lava in the outer core and the world geometry of planetary magnetic fluxes that are spaced out to interplanetary space. This combined method is known to guide both models of planetary magnetism and practical uses that touch on navigation, atmospheric science, and the minimization of disturbances caused by the sun.

Origin of the Earth’s Magnetic Field

1. The Dynamo Effect

One of the earliest ideas about Earth’s magnetic field assumed that a giant bar magnet was buried deep inside the planet, aligned with its axis of rotation. While simple, this explanation is incorrect. Today, the accepted theory is that the magnetic field is generated by the dynamo effect.

In this process, electric currents develop in the outer core of the earth, as a result of the convectional movement of molten metallic fluids, mainly iron and Nickel. By the application of Maxwell equations, these currents create a magnetic field. The rotation of the earth along its axis causes the Coriolis force to organize the currents in spiral patterns to maintain a steady magnetic field over periods of geologic time. This geodynamic mechanism is also known as a geodynamo.

2. Magnetic Dipole Approximation

Although the true origin is due to dynamo action, the Earth’s magnetic field at the surface can be approximated as if it were generated by a magnetic dipole placed at the Earth’s center. However, the dipole axis does not exactly coincide with the Earth’s rotational axis. The angle between them is about 11.3°.

This misalignment means that the magnetic poles do not coincide with the geographic poles, leading to concepts like magnetic declination.

Magnetic Poles and Equator

1. Location of Magnetic Poles

The points where the Earth’s magnetic field lines are vertical are called the magnetic poles. At present, the north magnetic pole is located at approximately 79.74° N, 71.8° W in northern Canada, while the south magnetic pole lies at 79.74° S, 108.22° E in Antarctica.

These locations are not fixed but drift slowly over time due to changes in the Earth’s core dynamics.

2. Confusion in Nomenclature

Unlike a bar magnet, where magnetic field lines emerge from the north pole and enter the south pole, the Earth’s field behaves differently. In reality, the magnetic field lines enter the Earth near the north magnetic pole and emerge from the south magnetic pole (see Fig. 1).

This means that the north magnetic pole of the Earth actually behaves like the south pole of a bar magnet. Historically, it was called the “north magnetic pole” only because the north end of a compass needle points towards it. This naming convention creates confusion but is widely accepted in geomagnetism.

Strength of the Earth’s Magnetic Field

1. Field Intensity

The magnetic field of the Earth is spatially varying; its strength varies in the geographical areas and is usually between 25 μT (microtesla) at the equatorial points to about 65 μT (microtesla) along the polar sections. The strength of the field on average is of the order 10⁻⁵ T.

2. Estimating the Dipole Moment (Example 1)

We can estimate the Earth’s magnetic dipole moment using its equatorial field.

From physics, the field at the equator of a dipole is:

B_E = μ₀m / 4πr³

where:

B_E = equatorial magnetic field (≈ 0.4 G = 4 × 10⁻⁵ T)
r = radius of Earth (≈ 6.4 × 10⁶ m)
m = dipole moment of Earth

Rearranging:

m = 4πr³ B_E / μ₀

Substituting values:

m = 4π(6.4×10⁶)³(4×10⁻⁵) / 4π×10⁻⁷

m ≈ 1.05×10²³ A⋅m²

This value is close to the reported geomagnetic dipole moment of 8 × 10²² A·m².

Magnetic Declination and Dip

1. Magnetic Declination

Magnetic declination, denoted as D, is defined as the angular difference between the direction of magnetic north, which is shown by a compass needle, and the real geographic north, which is a phenomenon that usually shows slight differences on the surface of the Earth.

This is shown in Figure 2, which shows the geographic meridian to be the line that links the true north and south, and the magnetic meridian to be the line that links the magnetic north and south. The angular difference between these two meridians is the declination.

Experimental observations to the whole of India indicate that the shrinkage has not been very great: about 0°41 to the east at Delhi and 0°58 to the west at Mumbai.

2. Magnetic Dip (Inclination)

A magnetic needle should not be kept horizontal when pivoted such that the needle can swing in a vertical plane, i.e. in the magnetic meridian. Instead, it takes an angle with the horizontal, which is known as the angle of dip (I), as shown in Figures 3 and 4.

At the equator, I=0°, while at the poles, I=90°.

3. Components of Earth’s Field

The Earth’s magnetic field at any point B_E can be resolved into two components:

Horizontal component, H_E = B_Ecos I
Vertical component, Z_E = B_Esin I

Thus,

tan I = Z_E / H_E

This relationship is fundamental for measuring and analyzing the Earth’s magnetic field.

Elements of the Earth’s Magnetic Field

To completely describe the Earth’s field at any location, three elements are specified:

Declination (D) – the angle between true north and magnetic north.
Inclination or Dip (I) – the angle made by the field with the horizontal.
Horizontal Component (H_E) – the magnitude of the field along the horizontal direction.

These elements together define the magnetic environment at any geographical point.

Behavior of Compass Needles at the Poles

The functioning of a compass is assumed based on its orientation to the horizontal part of the magnetic field of the Earth. This horizontal component, however, is insignificant at polar latitudes as the field lines are mostly vertical.

Therefore, when the conditions are polar, a traditional compass will not point to the North direction. Rather, they are aligned with the magnetic field inclination using a dip needle, which is free to vibrate in a vertical plane (see Fig. 4). The needle is pointed straight down at the poles that are magnetic.

Applications and Importance of Earth’s Magnetism

1. Navigation

The magnetic field of the Earth has been used in navigation since antiquity. Magnetic compasses still remain a necessary tool to explorers, mariners, and sometimes land-going tramps.

2. Protection from Solar Radiation

The geomagnetic field bends the charged particles that are emitted by the Sun, and hence, harmful radiation does not reach the surface of the Earth. The process leads to such effects as auroral displays that are seen in polar latitudes.

3. Geological Insights

Paleomagnetic studies that are particular in the study of remanent magnetization that has been retained in both sedimentary and igneous rocks allow geologists to reconstruct plate tectonic behavior and continental drift.

4. Space Science

The magnetic field of the Earth has to be considered in satellite and spacecraft planning and designing of communication systems.

Worked Example (Example 2)

Problem: In the magnetic meridian of a certain place, the horizontal component of Earth’s field is 0.26 G and the dip angle is 60°. Find the total magnetic field.

Solution:
From Fig. 4,

H_E = B_Ecos I

So,

B_E = H_E / cos I = 0.26 / cos 60° = 0.26 / 0.5 = 0.52 G

Thus, the total magnetic field at the location is 0.52 G.

Conclusion

The magnetism of the Earth is a great natural phenomenon that brings together deep Earth activities and applications on the surface. Produced by the geodynamo in the molten core, it may be mathematically modeled as a tilted magnetic dipole, and consequently, the terms declination, dip, and the individual field components are produced.

Despite its relative weakness when compared to the artificial magnets, the geomagnetic field has immense power over the planet, and it controls navigation systems, helps geologists to do their studies, as well as provides protection against harmful radiation to biological life. The diagrammatic illustrations of Fig.1, a wide-scale representation of a dipole, and Fig. 4, a dissection of the field into building blocks, demonstrate that the magnetism of Earth is not, in fact, an abstract concept but rather, it is an underlying force that links the physics, geology, as well as human discovery.
